Крепежная пластина с торцевым креплением

Описание

Крепежная пластина с торцевым креплением

– CNC Precision Aluminum Motor Mounting Plate for Linear Motion Systems

     Этот Крепежная пластина с торцевым креплением, specifically engineered for CNC machines and linear transmission assemblies. Designed as a critical structural component, this plate provides a rigid mounting interface for motors and linear modules, ensuring accurate alignment and smooth operation.

Изготовлено из 12mm thick 6061-T5 aluminum alloy, this end mount plate offers exceptional strength, rigidity, and dimensional stability. The black anodized surface enhances corrosion resistance while delivering a professional finish suitable for industrial applications.

Equipped with countersunk screw holes, the plate ensures a flush mounting surface, reducing interference and improving assembly accuracy. Additionally, it features pre-machined threaded holes compatible with NEMA 23 stepper motors, enabling easy and precise motor installation.

Основные характеристики

• High Structural Rigidity: 12mm thick aluminum for superior strength and stability
• Precision Motor Mounting: Pre-configured for NEMA 23 stepper motors
• Countersunk Hole Design: Ensures flush surface installation
• Black Anodized Finish: Enhanced corrosion resistance and wear protection
• Accurate Alignment: Improves motion precision and reduces system error
• Durable & Lightweight: Ideal for long-term industrial use

Приложения

• CNC routers and milling machines
• Linear motion systems and actuators
• 3D printers and automation equipment
• Robotics and precision machinery
• Механические узлы на заказ

Производственный процесс

• CNC Precision Machining (milling, drilling, and contour cutting)
• High-Precision Boring (for alignment-critical features)
• Thread Tapping (for NEMA 23 motor mounting holes)
• Countersinking (for flush screw installation)
• Обработка поверхности (удаление заусенцев и полировка)
• Surface Treatment (black anodizing for corrosion resistance)
• Final Inspection (dimensional accuracy and flatness verification)

Допуски и размеры

• Material Thickness: 12 mm ±0.05 mm
• Ровность поверхности: ≤0.03 mm
• Допуск по положению отверстия: ±0,02–0,05 мм
• Точность резьбы: Соответствует метрической системе ISO
• Mounting Interface Accuracy: High precision for motor alignment
• Допуски на размеры: ±0.05 mm (customizable)

Возможности производства по схемам OEM / ODM

As a professional OEM/ODM manufacturer, we specialize in precision CNC machined components for motion control and automation systems. With advanced machining capabilities and strict quality control, we deliver customized mounting solutions tailored to your specific requirements.

• Custom dimensions, hole patterns, and thickness
• Compatibility with different motor standards (NEMA series)
• Выбор материала с учетом прочности и требований конкретного применения
• Surface finishing options (anodizing, coating, custom colors)
• Гравировка логотипа и нанесение собственной маркировки
• Быстрое прототипирование и масштабируемое производство

If you are sourcing a “End Mount Plate”, CNC end mount plate, motor mounting plate, NEMA 23 mount plate, aluminum CNC plate, linear motion mounting plate, CNC machine accessory, anodized aluminum plate OEM， we offer reliable, precision-engineered solutions tailored to your market. Свяжитесь с нами Обращайтесь к нам по вопросам OEM-адаптации, получения образцов или расчета стоимости оптовых заказов.
