Shaft Collar

Description

Shaft Collar

– Precision CNC Machined Shaft Locking Ring for Secure Positioning

     Le Shaft Collar, a versatile mechanical component designed to secure, locate, and space parts on a shaft. Widely used in power transmission, automation systems, and machinery assemblies, this collar provides a simple yet highly effective solution for axial positioning and load distribution.

Manufactured with high precision using advanced CNC machining processes, our shaft collars deliver excellent concentricity, tight tolerances, and consistent clamping force. Available in multiple designs such as set screw type, one-piece clamp, and two-piece split collar, they offer flexibility for various installation and performance requirements.

Constructed from high-quality materials including carbon steel, stainless steel, or aluminum alloy, these collars ensure durability, corrosion resistance, and long service life even in demanding industrial environments.

Caractéristiques principales

• Secure Shaft Positioning: Prevents axial movement of components
• Multiple Designs Available: Set screw, one-piece clamp, and split collar options
• Usinage de haute précision: Ensures accurate fit and concentricity
• Strong Clamping Force: Reliable holding without shaft damage (clamp types)
• Matériaux résistants à la corrosion: Suitable for various environments
• Easy Installation & Adjustment: Quick mounting and repositioning

Applications

• Industrial automation systems
• Power transmission assemblies
• Motors, gearboxes, and drive systems
• CNC machinery and robotics
• Packaging and conveyor equipment

Processus de fabrication

• CNC Precision Machining (turning, milling, and boring)
• Precision Boring (for accurate shaft fit)
• Thread Tapping (for set screws or clamp bolts)
• Slot Cutting (for split collar designs)
• Heat Treatment (for enhanced strength and wear resistance, steel types)
• Surface Finishing (deburring and polishing)
• Surface Treatment (black oxide, anodizing, or passivation)
• Final Inspection (dimensional accuracy and clamping performance testing)

Tolérances et dimensions

• Tolérance du diamètre de l'alésage: H7 / ±0,01–0,02 mm
• Tolérance du diamètre extérieur: ± 0,02 à 0,05 mm
• Concentricité: ≤ 0,02 mm
• Clamping Surface Accuracy: High precision for uniform load distribution
• Thread Accuracy: ISO Metric / UNC / UNF compliant
• Tolérance dimensionnelle: ± 0,02 à 0,05 mm

Capacités de fabrication OEM / ODM

As a professional OEM/ODM manufacturer, we specialize in precision CNC machined mechanical components for industrial and automation applications. With advanced machining and quality control systems, we deliver customized shaft collar solutions tailored to your exact specifications.

• Custom bore sizes and collar dimensions
• Design variations (set screw, clamp, split types)
• Material selection for different environments and loads
• Surface treatment options for corrosion resistance and durability
• Gravure de logos et étiquetage personnalisé
• Prototypage rapide et production en grande série

If you are sourcing a “Shaft Collar”, shaft locking collar, split shaft collar, clamp collar, CNC shaft collar, precision shaft ring, shaft positioning collar OEM，we offer reliable, precision-engineered solutions tailored to your market. Contactez-nous N'hésitez pas à nous contacter pour toute personnalisation OEM, demande d'échantillons ou devis pour des commandes en gros.
